Rosemount-K-2051 In-Line Pressure Transmitter 1199 Seal and 319

Rosemount™ 2051 In-Line Pressure Transmitter, 1199 Seal and 319 Flushing Rings

사양

Rosemount™ 2051 인라인 압력 트랜스미터
보증
최대 5년 제한 보증
Rangedown
최대 100:1
통신 프로토콜
4-20mA HART®, WirelessHART®, FOUNDATION™ Fieldbus, PROFIBUS®, 1-5V 저전력 HART®
측정 범위
최대 10000psi(689.47bar) 게이지, 최대 10000psia(689.47bar) 절대압
공정 접액부 재질
316L SST, Alloy C-276
진단
기본 진단
인증/승인
독립적인 타사 IEC 61508에 따라 SIL 2/3 인증, NSF, NACE®, 위험 지역, 모든 인증 목록은 전체 규격 참조
Rosemount™ 319 Flushing Rings
Valve Type
Available with Ball, Needle or Gate Valves
Process Wetted Material
SST
SST Sour Gas
Alloy 625
Alloy C-276
Alloy 400
Packing Material
PTFE
Graphite
Connection Type(s)
Flushing Connections:
0, 1 or 2 connections
Welded: SW, Butt-Weld
Threaded: 1/4", 1/2", 3/4" NPT, RC1/4, RC1/2, RC3/4, F250C, F375C F562C

특징

Rosemount™ 2051 인라인 압력 트랜스미터
  • 간단하고 비용 효율적인 설치를 위한 직관적인 로컬 운영자 인터페이스(LOI)로 시운전이 간소화됩니다.
  • IEC 61508에 따른 타사의 SIL 2/3 인증 및 안전한 설치를 위한 FMEDA 데이터의 사전 사용 인증서
Rosemount™ 319 Flushing Rings
  • Less labor, faster installations
    • Pre-assembled - no need for multiple vendor piece parts.
    • Factory leak tested for reliable in-field performance.
    • Fast maintenance for substantial process uptime.
  • Drastically Reduces Maintenance time
    • A simple way for maintenance staff to safely vent or drain excess pressure in the line.
    • A convenient method to access process fluid for sampling.
    • Can calibrate against a known pressure without disassembling the instrument connection.
  • Works with nearly any process type
